ECE LAB 7: EMBEDDED SYSTEMS AND MICROCONTROLLER LAB

ECL-7



S. No. System Configuration Make Quantity
1 Model No. HP280G2MT
Core i5-6500 cup @3.00 GHz with 8GB RAM and 1 TB HDD
(Windows 10 professional)
HP 5



S.NO. SOFTWARE
1 Keil -µ Vision V4.00,Tool chain -Realview MDK-ARM.Vision-4.00,Keil Software,Inc
2 Flash Magic,Vision-3.71.245,Embedded System Academy Inc.Divers-8051 IXADiver version 2.39.241,ARM Diver Version 1.28.243
3 MPLAB TDE Version 8.83.00.00,Microchip Technology Inc ,USA
4 Code Composer Studio V-6, Version 6.1.0.00104Texas Instrument



S.NO. NAME OF EQUIPMENT MAKE QTY.
1 Bluetooth Application Board Advance Technology 2
2 GSM Application Board Advance Technology 2
3 12-Bit ADC-DAC Board Advance Technology 2
4 Graphical LCD Board Advance Technology 2
5 RF Receiver Board Advance Technology 2
6 ADSP 2181 Application Board Advance Technology 1
7 Sensor Board Advance Technology 2
8 Wi-Fi Application Board Advance Technology 1
9 Micro Controller Programmer Advance Technology 2
10 8085 Microprocessor Tr. Kit Excel Technologies 10
11 8086 Advance Microprocessor tr. Kit Excel Technologies 10
12 8031 Micro Controller Kit Excel Technologies 5
13 8051 Micro Controller Kit Excel Technologies 5
14 Power Supply With Cable Excel Technologies 30
15 8255 Study Card Excel Technologies 2
16 8279 Study Card Excel Technologies 1
17 8253 Study Card Excel Technologies 1
18 8251 Study Card Excel Technologies 1
19 8257 Study Card Excel Technologies 1
20 8259 Study Card Excel Technologies 1
21 8212 Study Card Excel Technologies 1
22 Buffer, Latch Decoder Card Excel Technologies 1
23 8 Channel ADC Module Excel Technologies 1
24 Universal Embedded Trainer (ET-VET) (Under TIEDC) Excel Technologies 10
25 Daughter Board (MSP-430) (Under TIEDC) Excel Technologies 5
26 Daughter Board (PIC16F877) (Under TIEDC) Excel Technologies 5
27 Daughter Board (ARM7-LPC2148) (Under TIEDC) Excel Technologies 5
