ECE LAB 3 : DIGITAL ELECTRONICS AND LOGIC DESIGN LAB

ECL-3



S.NO. NAME OF EQUIPMENT MAKE QTY.
1 Project Board (BB12V) Vijayenta 15
2 Power Supply (LQ 6324) Aplab 15
3 Digital Multimeter Sanwa 1
4 8051/251 Single board Computer/Evaluation board with ADP PPI Adapter; (ESA KEIL MCBx51) Electro system 10
5 Power Supply; (ESA PS M2) Electro system 10
6 DAC for ADC & Temp. Sensor Interface, (IF-DADC) Electro system 10
7 4-Digit, 7 Segment LED Display Interface (IF-DIS) Electro system 10
8 Logic Controller Interface (IF-LC) Electro system 10
9 Traffic Lights Interface (IF-TRL) Electro system 10
10 4×4 Matrix Hex keyboard interface (IF-HEXKBD) Electro system 10
11 Function Generator (ST 4060) Scientech 2
12 Function Generator (ST 4061) Scientech 28
13 CRO (caddo 803) Scientech 6
14 CRO (caddo 803D) Scientech 9
15 Digital Multimeter (Rish 14S) Rishub 13
16 Project Board (ST 2610) Scientech 10
17 Digital IC Tester (LP01) Leaper 1
18 Digital Multimeter (4022) Scientific 1
19 Ex-OR/Ex-NOR Gate Trinity 3
20 4-Bit ALU (DT-538) Trinity 4
21 Basic Logic Gate Trinity 1
22 TTL-CMOS-TTL Interface (DT-535) Trinity 1
23 4-Bit Binary Full Adder & Subtractor (DT-514) Trinity 1
24 Master Slave JK FF (DT-517) Trinity 1
25 Read Only Memory (DT-539) Trinity 5
26 BCD to 7 Segment Decoder (DT-546) Trinity 1
27 Logic Training Board (LTB-811) Trinity 1
28 8-Bit ADC (LTB-833) Trinity 1
29 4-Bit DAC (DT-553) Trinity 2
30 16 to 1 Multiplexer (DT-549) Trinity 1
31 Digital Lab Bread Board (ST2611) Scientech 4
